5 Inch Anti Glare Tempered Glass
Premium 5-inch Anti-Glare (AG) tempered glass cover lens for enhanced display readability. Reduces reflections, resists fingerprints & scratches. OEM/ODM manufacturer. Request a quote & free samples!
Description
Meta Description
Premium 5-inch Anti-Glare (AG) tempered glass cover lens for enhanced display readability. Reduces reflections, resists fingerprints & scratches. OEM/ODM manufacturer. Request a quote & free samples!
Product Overview
Designed for challenging lighting environments, our 5-inch Anti-Glare (AG) Tempered Glass Cover Lens significantly enhances screen clarity and usability. By effectively reducing reflections and glare, it minimizes eye strain and delivers exceptional visual performance-even under direct sunlight or bright indoor lighting.
Ideal for outdoor equipment, industrial HMIs, automotive displays, and high-end consumer electronics, this cover lens combines advanced glare-diffusion technology with the superior strength of tempered glass. Every unit is engineered for scratch resistance, touch sensitivity, and long-term durability.
Technical Specifications
|
Parameter |
Specification |
|
Diagonal Size |
5.0 Inch |
|
Material |
High-Alumina Silicate Glass |
|
Available Thickness |
0.5mm, 0.55mm, 0.7mm, 1.0mm, 1.1mm, 1.8mm (Custom available) |
|
Tempering Process |
Chemical Strengthening |
|
Surface Hardness |
≥ 9H (Pencil Hardness Test) |
|
Light Transmittance |
> 90% |
|
Gloss Level |
Typically 80±10 ~ 100±10 (Customizable upon request) |
|
Reflectance |
< 1% (Dramatically reduced from standard 8%) |
|
Coating Options |
Standard: Anti-Glare (AG). Optional: Anti-Fingerprint (AF), Anti-Reflective (AR) |
|
Printing Options |
Silk-screen printing (Black/White, Logos, Icons), Border Masking |
|
Shape |
Fully Customizable (CNC Cutting, Polished Edges, Custom Corners) |
How is tempered cover glass different from standard cover glass?
Tempered cover glass undergoes a specialized strengthening process (physical or chemical tempering) to significantly improve its mechanical properties. Key differences include:
Higher Hardness
Tempered glass achieves a 9H pencil hardness rating (compared to standard glass's 6-7H), offering exceptional scratch resistance.
Impact Resistance
Chemical tempering creates high compressive stress, making it 5x more impact-resistant than untreated glass.
Safety
When broken, it fractures into small, blunt pieces rather than sharp shards, reducing injury risks.
FAQ
Q: How does Anti-Glare (AG) glass differ from standard glossy cover glass?
A: AG glass has a microscopically rough surface that scatters reflected light, eliminating sharp reflections and glare. Standard glass has a smooth, mirror-like surface that causes strong reflections, making the screen difficult to see in bright light.
Q: How does chemical tempering enhance glass strength?
A: Chemical tempering involves ion exchange: glass is immersed in molten potassium salt (e.g., KNO₃), replacing smaller sodium ions with larger potassium ions. This creates a compressed surface layer, boosting:
Surface Hardness: Up to 9H rating.
Flexural Strength: Resistance to bending and impacts
Q: Can I get samples to test before placing a bulk order?
A: Yes, we provide functional samples for evaluation. Please contact our sales team to request samples.
Q: What is the typical lead time for mass production orders?
A: Lead times vary based on order size and customization. Generally, it takes 2-3 weeks for mass production after final approval. Contact us for a precise schedule.
Q: Do you offer full lamination services with touch sensors and displays?
A: Absolutely. Our vertical integration allows us to supply the complete laminated module (AG Cover Glass + Capacitive Sensor + Display), ensuring optimal optical performance and simplifying your supply chain.
Contact Us
Ready to Integrate Superior Glare Protection into Your 5-Inch Displays?
Contact our engineering team today for a competitive quotation, free samples, and technical consultation. Let us help you enhance your product's usability and durability.
