10.1 Inch TFT LCD Touch Screen Display
The 10.1" TFT LCD Touch Screen Display integrates a high-brightness TFT LCD and a projected capacitive touchscreen (CTP) through optical bonding technology. Designed for industrial and commercial durability, it delivers ultra-responsive 5-point touch control, enhanced optical clarity (≥85% transmittance), and robust performance in extreme temperatures (-20°C to 70°C). Ideal for outdoor kiosks, medical devices, industrial HMI, and interactive digital signage.
Description
Product Brief
The 10.1" TFT LCD Touch Screen Display integrates a high-brightness TFT LCD and a projected capacitive touchscreen (CTP) through optical bonding technology. Designed for industrial and commercial durability, it delivers ultra-responsive 5-point touch control, enhanced optical clarity (≥85% transmittance), and robust performance in extreme temperatures (-20°C to 70°C). Ideal for outdoor kiosks, medical devices, industrial HMI, and interactive digital signage.
Technical Specifications
|
Parameter |
Details |
|
Display |
10.1" TFT LCD, 1024×600 resolution, 16.7M colors, LED backlight |
|
Touch |
Projected capacitive, 5-point, glass surface hardness ≥6H |
|
Brightness |
550 cd/m² |
|
Viewing Angles |
170°(H)/170°(V) IPS Full Angle |
|
Interface |
12C/ USB(touch), RGB 24-bit( LCD), HDMI(optional) |
|
Operating Temp. |
-20°C to 70°C |
|
Contrast Ratio |
600~800 |
|
Customizable Support |
Glove/Wet-Hand operation |
Key Features & Advantages
1. Superior Optical Performance
- Optical Bonding: Minimizes glare and reflection, boosts sunlight readability, and achieves ≥88% transmittance for vivid visuals.
2. Industrial-Grade Durability
- Wide Temperature Range: Operates reliably from -20°C to 70°C and withstands storage at -30°C to 80°C.
- Long Lifespan: Supports >1 million touch cycles (up to 60 million for premium models).
3. Advanced Touch Performance
- Multi-Touch Performance: Enables pinch-to-zoom, rotation, and gesture controls with <5ms response time.
- High Accuracy: ±0.5mm touch precision (center) and zero drift after calibration.
- Glove/Wet-Hand Operation: Supports touch input in challenging conditions (e.g., rain, industrial gloves)
Target Applications
Outdoor Kiosks
High brightness (550 cd/m²) and anti-glare for ticket machines, ATMs, and vending systems.
01
Industrial Control
Dust/impact-resistant design for factory HMIs, robotics, and test equipment.
02
Healthcare
Easy sterilization for medical carts and diagnostic tools.
03
Retail & Hospitality
Gesture-based menus, signage, and POS systems.
04
Transportation
Dashboard displays for fleets and aviation
05
FAQ
Q1:Why Choose Our 10.1" TFT LCD Touch Screen Display?
A: Direct Factory Pricing: Customizable specs without middleware markups.
Safety Stock Raw Material: Multi-sourcing critical parts (controllers, FPCs) from 3+ fabs. 98% on-time delivery since 2023.
Global Support: 48hr technical response, 2-year warranty, and flexible logistics methods.
Q2: Can it survive outdoor UV exposure?
A: Absolutely. The optically bonded laminate blocks 99% of UV damage and reduces reflection.
Q3: Do you support small-batch prototyping?
A: We offer 5–50 unit prototype runs with a 3-week lead time. Includes full validation testing (touch linearity, EMC, thermal cycling).
Contact us for volume discounts and OEM solutions
Email: mingqisales@gmail.com
Phone: +86-133-52983735
