6.86 Inch Bar LCD Capacitive Touchscreen
Designed for tight spaces, this 6.86 inch tft touch screen slim module reimagines how devices display information and respond to touch, making it ideal for applications where traditional square or rectangular screens are insufficient.
Description
Product Overview
Designed for tight spaces, this 6.86 inch tft touch screen slim module reimagines how devices display information and respond to touch, making it ideal for applications where traditional square or rectangular screens are insufficient.
Technical Specifications
|
Parameter |
Details |
|
Size |
6.86 inch (diagonal) |
|
Aspect Ratio |
8:3 (1280 × 480 pixels) |
|
Touch Technology |
Projected Capacitive (5-point multi-touch) |
|
Response Time |
≤5ms |
|
Brightness |
500 nits (up to 700 nits on request) |
|
Viewing Angle |
IPS Full View |
|
Active Area |
60.2208 mm(H)×160.5888 mm(V) |
|
Contrast Ratio |
900:1 (Typ.) |
|
Bonding Method |
Optical Bonding/ Air Bonding (Optional) |
|
Operating Temperature |
-20°C to 70°C |
|
Storage Temperature |
-30°C to 80°C |
|
Cover Lens Material |
Chemically strengthened glass (6H hardness) |
|
Interfaces |
4-lanes MIPI interface for TFT; I2C/USB for Touch Panel |
|
Certification |
RoHS, ISO 9001, IATF 16949 (optional) |
Our Core Manufacturing Advantage: Vertical Integration
We are not just a manufacturer; we are a factory with complete control over our supply chain. This unique position allows us to offer you significant benefits:
Our Own Cover Glass Factory: We cut, shape, polish, and chemically strengthen (like Gorilla Glass) our own cover glass. This allows for unlimited customization of:
- Shape: Custom cutouts, notches, and unique geometries.
- Thickness: Various thicknesses to meet structural and optical needs.
- Surface Treatment: Anti-Glare (AG), Anti-Fingerprint (AF), and Anti-Reflective (AR) coatings.
- Printing: Custom border printing (Black, White, any Pantone color) and logo printing.
Our Own Touch Panel Factory: We manufacture our own capacitive touch panels (Glass+Glass/ Glass+Film/ Glass+Film+Film/ PET+Film). This enables deep customization of:
- Sensor Pattern: Tailored to your specific size, shape, and performance requirements.
- Number of Touch Points: Customize firmware for specific gesture support.
- Performance: Optimize for gloved hand or stylus use.
Certifications: Quality You Can Trust
Our commitment to excellence is validated by global standards:
ISO 9001
Ensuring consistent quality management across production.
IATF 16949
Compliance with automotive industry rigorous standards (available for automotive-focused orders).
RoHS
Free from hazardous substances, meeting environmental regulations worldwide.
Ready to Innovate?
Whether you're designing the next smart appliance, industrial control system, or automotive interface, our 6.86 inch bar LCD capacitive touchscreen is built to elevate your product. Contact us today for samples, technical specs, or a personalized quote.
Email: mingqisales@gmail.com
Phone: +86-133-52983735
Where slim design meets big performance.
FAQ
Q: 1. Does optical bonding increase cost significantly?
A: No, just a little bit. And eliminates air gaps (better readability) and strengthens impact resistance. ROI in end-use applications.
Q: 2. Is the touch screen resistant to water and dust?
A: The standard version has a basic IP54 - level protection, safeguarding against light dust ingress and splashes. For applications needing higher protection (like IP65 or above), we offer customized sealing solutions. Contact us to discuss your specific environmental requirements.
Q: 3. Is anti-glare coating available?
A: Yes. An optional coating reduces glare by 60% for sunlight readability.
Q: 4. What is the lead time for mass production orders?
A: For mass production orders, the lead time is usually 15-21 business days, depending on the order quantity and customization requirements. We will provide a more accurate lead time when you place the order.
