9.66 Inch Car TFT Touchscreen Panel
Our 9.66 inch car TFT touchscreen panel is purpose-built for this critical role: featuring a unique 320×1280 resolution, 450 nits brightness, high-speed MIPI interface, and robust 40pin configuration. Designed exclusively for automotive environments, this module marries form and function to deliver seamless in-vehicle interactions—whether for infotainment, navigation, or vehicle controls.
Description
introduction
The 9.66-inch Car TFT Touchscreen Panel is a wide-format TFT LCD display module designed for in-vehicle visual interfaces. It is suitable for rearview mirror displays, dashcam systems, or smart automotive terminals.
Technical Specifications
|
Parameter |
Details |
|
Display Size |
9.66 inches (diagonal) |
|
Resolution |
320 × 1280 pixels (1:3.8 aspect ratio) |
|
Brightness |
500 nits (typ.) with auto-dimming support |
|
Interface |
MIPI-DSI (2-lane, up to 1.5Gbps per lane) |
|
Pin Configuration |
40pin FPC (automotive-grade, gold-plated) |
|
Operating Temperature |
-40°C to 85°C (AEC-Q100 Grade 2 compliant) |
|
Storage Temperature |
-55°C to 95°C |
|
Touch Technology |
Projected capacitive (10-point, glove-compatible) |
|
Touch Response Time |
<50ms |
|
EMI/EMC Compliance |
CISPR 25 Class 5 (highest automotive standard) |
|
Cover Lens |
Chemically strengthened glass (7H hardness) with anti-glare/anti-fingerprint coating |
|
Power Consumption |
Typical: 3.5W; Sleep mode: <0.1W |
Key Features
Optimized Resolution
320 × 1280 pixels (1:3.8 aspect ratio), tailored for dashboards, displays layered information (navigation, media, vehicle data) in a single view, reducing UI clutter and driver distraction.
01
Adaptive Visibility
500 nits brightness with auto-dimming via ambient light sensing maintains no glare in sunlight and reduces eye strain in low-light conditions.
02
Automotive-Grade Interface
MIPI-DSI interface delivers high-speed, low-latency signal transmission, minimal EMI and broad compatibility with mainstream automotive SoCs, ensuring stable operation.
03
Reinforced FPC Design
Durable 40-pin FPC resists vibration (up to 20G) and temperature variation (-40°C to 85°C), performing reliably in harsh driving environments.
04
Responsive Touch Performance
10-point capacitive touch with great sensitivity supports glove operation and fast response under moisture (e.g., spills).
05
applications
- Digital rearview mirror systems
- Dashcam displays
- Automotive central control or infotainment systems
- Parking assistance and reversing camera displays
- Fleet management or commercial vehicle monitoring terminals
why choose us
As a leading capacitive touch screen manufacturer with 8 years of experience, we are committed to delivering quality, innovation, and continuous technological advancement.
1. R&D Capabilities
- Our dedicated R&D team of over 10 engineers and materials scientists drives innovation in touch technology.
- We collaborate with academic institutions and industry leaders, and currently hold 38 patents in sensor design, signal processing, and durability.
- Our in-house laboratory continuously tests new materials and algorithms to improve responsiveness, reduce power consumption, and enhance environmental resistance.
2. State-of-the-Art Facilities
Our 3,000 m² manufacturing campus features:
- Eight fully automated production lines equipped with precision laser cutting and etching systems
- ISO 9001- and IATF 16949-certified manufacturing and quality management systems
- Advanced in-house laboratories with environmental chambers, vibration testers, and life-cycle simulators
- A monthly production capacity of over 300,000 touch panels, ensuring reliable and timely delivery for orders of all sizes
3. Product Lifecycle Support
Technical Documentation
MIPI interface schematics and 3D CAD models for seamless integration.
PPAP Submission Support
Assistance with Production Part Approval Process documentation for OEM qualification.
Warranty
2-year automotive-grade warranty (industry-leading) with failure analysis for any field issues.
Packaging & Delivery
- ESD-Safe, Automotive Packaging: Anti-static trays + foam-lined, moisture-barrier cartons with serialized labels for traceability (critical for automotive supply chains).
- Delivery Timelines:
Sample units: 7–10 business days.
Production orders: 18–22 business days (aligned with automotive JIT delivery schedules).
Global Shipping: Dedicated automotive freight partners with temperature-controlled options for sensitive components.
FAQ
Q1: Is this panel compatible with both front and rear cameras?
Yes. It typically supports dual-channel video input, allowing integration with front and rear cameras for simultaneous or switchable display.
Q2: Is the panel suitable for outdoor automotive environments?
Yes. With a typical operating range of -40°C to 85°C, it is designed to withstand temperature fluctuations.
Q3: Does the display support customization (brightness, interface, bonding)?
Yes, we support customization such as brightness enhancement, optical bonding, interface selection, and touch panel tuning for OEM/ODM projects.
Q4: What after-sales support do you provide?
We offer a 2-year warranty. In case of any field issues, our engineering team provides failure analysis and corrective actions to minimize downtime and risk.
Whether you're designing a next-gen SUV console, electric vehicle dashboard, or rear-seat system, our 9.66 inch car TFT touchscreen is engineered to elevate in-vehicle experiences. Contact our automotive team for samples, compatibility testing, or a tailored quote.
Email: mingqisales@gmail.com
Phone: +86-133-52983735
Engineered for the road-where every touch moves you forward.
